หัวแบ่ง SEMI-UNIVERSAL BS-2

UNIVERSAL DIVIDING HEAD : BS-2  หัวแบ่ง Model: BS-2

FEATURES :

The HOMGE'S Universal Dividing Head has been designed to carry out all types of gear cutting. Precision dividing and spiral work (except Type BS-0, and BS-1) with greater precision and efficiency than has been possible before. The center face can be tilted from a horizontal position of 90o down to -10o from vertical, and inclinations can be read off a scale graduated in degrees.  The center is built to highest engineering standards and is factory inspected and tested to assure complete satisfaction. The ratio of worm to gear is 1:40.

OPTIONAL ACCESSORY :

3-Jaw Chuck

6" or 7" 3-Jaw Chuck

for BS-2

 REMARK:

" Operation and Service Manual "  provided for reference.
